Electrical Characteristics | |
Communication ISO Protocol | ISO/IEC 18000-6C, EPC Global C1G2 |
Operating Frequency band | 865 MHz – 928 MHz |
Chip type | Alien Higgs 9, Monza 4/4QT/5/R6/R6P, UCODE |
EPC | As per Chip |
Memory User | As per Chip |
Read Range | Up to 8 mt* (Fixed Reader) and 6 mt* (Handheld Reader) |
Physical Characteristics | |
Dimension | 100 mm x 15 mm x 10 mm |
Weight | 14gm± 1 |
Material | ABS/PC + Sponge and Glue on back side |
Packaging | 100 pieces/box packet |
Environmental Characteristics | 100,000 |
Operating Temperature | -40 to +85 °C |
Storage Temperature | -40 to +85 °C |
IP Rating | IP 68 |
Chemical Resistance | Resistant To Chemical Solvent and Moisture |
Shock & Vibration | Resistant to heavy shock and cont. vibration on conveyor belt |
Attachment | Adhesive, Magnets |
