Eco Track Systems

RFID Mifare Card

Model No: ETS-RC 01

Description

Mifare cards are one the most widely used cards in HF (13.56 MHz) frequency across the globe. It operates on 13.56 MHz (HF) frequency protocol and are ISO / IEC 14443 compliant. These cards are available in various memory sizes. These contactless smart cards are double side laminated and used for identification and authentication in a variety of applications like Identity cards, Library cards, access control, employee cards, membership card, loyalty cards, fuel card, hotel key card, micro payments, parking management etc.

The cards are designed with highest precision and are individually tested to guarantee high performance. The card surface is scratch proof and has a shiny mirror like effect which gives it a premium look.

We offer customized printing on both sides that include logo, photo, text, barcode QR code etc. depending on the requirement of the project. We use high quality printers for quality assurance.

Features

HF 13.56 MHz

ISO/IEC 14443

Glossy Look

Glossy Shine Look

PET Material

High Grade PVC

Water resistent

Chemical Resistant

Customized Printing

Scratch Proof Surface

Application Areas

Membership Card

Attendance Management

Loyalty Card

Access Control

Library Card

E-Payment Card

Health card

Health Card

Hotel Key Card

Hotel Key Card

Fuel Card

Fuel Card

Parking

Parking Management

Technical Specification

Model NumberMifare Card
Frequency13.56 MHZ
Chip OptionsMifare Classic (1k), Mifare Classic (4k), Mifare Ultralight,Mifare Ultralight EV1, Mifare Ultralight C, Mifare DESfire, Mifare DESfire EV1, I Code SLIX.
ComplianceISO 14443A
Working ModeRead and Write
Read and Write RangeDepends on chip and reader
Data retention10 years
Anti-CollisionYes
Base MaterialHigh Grade PVC
Operating Temperature-25 to +70 degree Celsius
Storage Temperature-25 to +50 degree Celsius
Operating Humidity<= 80%
Package200 Qty in 1 box
Weight1.5 kg per box
PrintingYes available for both side
LaminationDouble side coated
Dimensions86mm x 54mm x 0.78mm
