NFC Label
Model No: ETS-RT 12A
Application Areas
Open Mobile Applications
Make Calls
Send Messages
Write URL
Information Exchange
| Frequency | 13.56MHz |
| Standard/Protocol | ISO14443A |
| Chip type | NXP NTAG213/215/216,Ultralight(C) (customized) |
| Memory | 144/504/888/192 Byte |
| Reading range | 0-10CM(relates with the antenna,reader and working environment) |
| Dimension | Dia 25mm(customized) |
| Surface material | Coated Paper/PET(customized) |
| Printing craft | Silk screen printing,Rotary printing,offset printing,etc. |
| Data retention time | 10 years |
| Reading/Writing endurance | 100,000 times |
| Operating temperature | -10°C~+65°C |
