Mifare Card Reader & Writer

Model No: ETS-RD 07

Description

ETS-RD 07 is a High Frequency (HF) based RFID reader that works on 13.56 MHz frequency. It is fully compatible with ISO 15693 and ISO 14443 A global standards to read Mifare and I-code Cards & Tags. It is compact in nature and is widely used for projects related to access control, E-payments, Library automation, transportation, attendance management etc. The reader API's also contain propriety commands of Mifare and I-Code standards. It has an inbuilt buzzer for read identification and comes with a free read & write demo application software which can be used for plug and play applications.

Features

Frequency: 13.56 MHz

ISO 15693, ISO 14443 A,ISO 18000-3

Compatibility: Mifare, NFC

Compact Design

Make in India

USB

Quality: Industrial Grade

Plug and Play

IP65

Inbuilt LED & Buzzer

Application Areas

Programming & Tag/ Card Registration

Payment Application

Library

Access Control

Transportation

Transporation

Attendance Management

Technical Specification

MaterialABS
ColourWhite
MemoryNA
Thickness15 mm
Size (in mm)104mm x 63mm
Operating Frequency13.56 MHz
Standard / ProtocolsISO 14443A, ISO 15693
Temperature-0°C to +65°C
Integrated CircuitNA
AntennaInbuilt
Tag SupportedMifare / I-Code
Supply voltage5 VDC (USB)
Read RangeUpto 100 mm
InterfaceMicro USB
IndicatorsBuzzer, LED for power & read
Weight25 gms
